Sharanya Asked a Question
March 28, 2021 11:06 ampts 30 pts
58. A square wave of peak to peak amplitude of 500 mV has to be amplified to a peak to peak amplitude of 4V with a rise time of 3 us or less. The op-amp used should have a minimum slew rate of (A) 0.5 V/us (B) 0.75 V/us (C) 0.8 V/us (D) 1.1 V/us
  • 1 Answer(s)
  • 0 Likes
  • 1 Comments
  • Shares
  • Eduncle thankyou

    Hi Sharanya

    kindly refer below image

    thank you for asking

    • ans1.PNG
    Likes(0) Reply(0)
