A pendulum consists of a ring of mass m and radius r suspended by a massless rigiid rod of length/ attached to its rim. when the pendulum oscillates in the plan

A pendulum consists of a ring of masS M and radius R Suspended by a massless rigiId rod of length/ attached to its rim. When the pendulum oscillates in the plane of the ring, the time period of oscillation is ) 27R ) Ry V8 2R+2RI +12 sR+/) (c) 2T (d)2R +2R! +Py V8

3 Answer(s) Answer Now
  • 0 Likes
  • 4 Comments
  • 0 Shares
  • comment-profile-img>
    Chandra prakash Best Answer

    this is simplest and easiest method. for this type of questions... u should see this also.. dear I hope this will help you .and solving very fast.. best regards

    eduncle-logo-app

    I hope you got it my point dear ..

  • comment-profile-img>
    Abhishek singh

    A good question always comes with a good solution. Option C is correct.

    eduncle-logo-app

    Here alpha is angular acceleration.

    eduncle-logo-app

    and I have used parallel axis theorem to calculate the moment of inertia.

  • comment-profile-img>
    Dhairya sharma best-answer

    i think u felt uneasy in this term. see it carefully.
