Determine the lower frequency limit (critical frequency) for the integrator circuit shown below.

1 Answer(s) Answer Now
  • 0 Likes
  • 2 Comments
  • 0 Shares
  • comment-profile-img>
    Bidyut sinha

    Critical frequency for integrator has formula f2=1/2πCR2...here R2=100KiloOhm and C=0.01 micro Farad.. Apply this
