It is msq type

(a) 4, 4 (b) 4, 8 (c) 6, 6 a) 8, 4 At what angle(s) of incidence, X-rays of wavelength 5.0 A will produce diffracted beam from the (110) planes in a simple cubic lattice with a = 10 A (a) 6.80 5 In a diffractian exneriment with Y-ravs ofwavelength 1.54A. a diffraction line correspondng to 26 (b) 10.2 (c) 20.70 (d) 45.0

2 Answer(s) Answer Now
  • 0 Likes
  • 2 Comments
  • 0 Shares
  • comment-profile-img>
    Priyanshu kumar best-answer

    See this👇

    eduncle-logo-app

    got this reshav??

    eduncle-logo-app

    why we have calculated for n=2 here? i mean it is not asked then?

    eduncle-logo-app

    Dear reshav in ques it is asking angle(s)...so you have to check for first order diffraction...second order diffraction and match with the answer...here for n=1 and n=2 both the angles matches with the answer...so both are correct
