Nitish Kumar posted an Question
July 16, 2022 • 00:48 am
![]()
30 points
30 points
- IIT JAM
- Geology (GG)
. maximum dip of a plane can be obtained on a line that is at .. angle with strike of the bed. b. 45 d. 65 a. 25° c. 90° (du-2015)
. Maximum dip of a plane can be obtained on a line that is at .. angle with strike of the bed. B. 45 D. 65 A. 25° C. 90° (DU-2015)
1 Answer(s)
Answer Now
- 0 Likes
- 3 Comments
- 0 Shares
-
![comment-profile-img]()
>
Shubham deo
option C (90°) is the correct answer
-
![comment-profile-img]()
>
Sushmita Best Answer
The line of intersection of dipping beds with imaginary horizontal surface is called strike line. And the inclination of bed with horizontal measured on vertical plane is called dip. If dip is measured perpendicular (right angle:90°) to strike then it is called true dip and that dip is maximum. If dip measured other than true dip direction is called apparent dip and amount of apparent dip is always less true dip. For more clarification you can see in attached diagram. Here, strike (line 1) ,true dip [ direction 2 , perpendicular to line 1] and apparent dip [ direction 3]. So, correct option should be option C(90°).
![cropped5092357962142210765.jpg]()
Do You Want Better RANK in Your Exam?
Start Your Preparations with Eduncle’s FREE Study Material
- Updated Syllabus, Paper Pattern & Full Exam Details
- Sample Theory of Most Important Topic
- Model Test Paper with Detailed Solutions
- Last 5 Years Question Papers & Answers
Sign Up to Download FREE Study Material Worth Rs. 500/-
Nitish kumar Sahu
But the answer is given 45°. It is wrong I guess
