Himanshu posted an Question
May 18, 2020 • 06:31 am 30 points
  • IIT JAM
  • Physics (PH)

Optics when two simple harmonic oscillation.....

solve with the quickest way what is the basics of such kind questions in pic options and diagram of question are there.

3 Answer(s) Answer Now
  • 1 Likes
  • 8 Comments
  • 0 Shares
  • comment-profile-img>
    Abhishek singh Best Answer

    First read the solution, then read this comment. Here you need to check for two points, at t=0 and at some time t=π/2w(this is chosen such that everything cancle and just π/2 remain). These two points are showing a movement from point A to B with increase in time. This means the rotation is anticlockwise. Now it's homework time for you, do the same calculations for option B. there you can take alpha=0(you can do that, because it will never change your results (as relative phase remains same between Bita and alpha). Best regards.

  • Himanshu Pandey

    for second part B=3A is fine for first part how to find if direction is Also given in question say anticlockwise???

    eduncle-logo-app

    I was expecting this question from you. it should be asked by a curious student which you are! Now refer to my comment next comment about the sense of rotation, and let us talk about anticlockwise(as specified by you).

  • comment-profile-img>
    Ruby negi best-answer

    hope it is clear to you... b,c options are correct... for any doubt please ask...

  • comment-profile-img>
    Abhishek singh

    Here both option B and C could be the answer. Because they haven't specified sense of rotation. see the attached for better understanding. I am sure you will get what I am trying to say. Best regards.
